Coil Material	Coil	Color Steel, Galvanised
	Coil Thickness	0.3-0.8mm
	Coil Width	1000mm, Customized
	Yield Strenth	250-350Mpa
Decoiler	Decoiler Type	Manual or hydraulic or automatic type
	Weight Capacity	5T or 6T or 8T or 10T, customized
Main Roll Forming	Forming Station	18 forming stations, depend on profiles
	Roller Material	High grade 45# steel, surface with hard chrome 0.05mm
	Shaft Material	High grade 45# steel, quenched
	Shaft Diameter	76mm
	Drive Type	Chain Drive
	Forming Speed	0-15m/min
	Main Power	5.5KW
Cutting Device	Cutting Type	Hydraulic cutting
	Cutting Die Material	Cr12Mov steel, HRC58-62
	Cutting Tolerance	+/-1.5mm(10m)
Electrical System	PLC Brand	PANASONIC brand
	Inverter Brand	YASKAWA brand
	Encoder	OMRON brand
	Touch Screen	MCGS brand
Hydraulic System	Hydraulic Station	Famous Chinese Brand
	Hydraulic Power	3KW
Runout Table	Table Type	Simple non powe type table
	Function of Table	To support the profile sheets after cutting

 Main Components of Trapezoidal Sheet Roll Forming Machine
