Trailer Mounted Double Layer Roll Forming Machine

Contents

Trailer Mounted Double Layer Roll Forming Machine for IBR & Corrugated Sheet Profiles



Character of Double Layer Machine



This double layer roofing sheet roll forming machine is tailer mounted type, which can do site-working. One machine is to produce two different ibr & corrugated profiles.



Main Technical Specification:

  • Material thickness: 0.3-0.8mm with yield strength 200-300Mpa
  • Forming Station: 16 & 18 ( depend on profiles )
  • Main power: 7.5KW
  • Hydraulic power: 4KW
  • Machine diameter: about 10000x1500x1400mm (LXWXH)
  • Machine weight: about 9 Ton
  • Decoiler: manual or hydraulic type ( depend on customer's requirement )
  • Weight capacity of uncoiler: 5 Ton
  • Roller material: 45# bearing steel, polished and coated with 0.05mm hard chrome surface
  • Drive: chain transmission
  • Principal Axis material: 45# bearing steel
  • Axis diameter: 75mm ( depend on profiles )
  • Forming speed: 0-15m/min
  • Cutting: Hydraulic cutting

Trailer mounted double layer roll forming machine
